Siemens S7-1500 6ES7532-5HD00-0AB0 Analog Output Module
Siemens S7-1500 6ES7532-5HD00-0AB0- Analog Output Module AQ 4xU/I ST with 4 analog outputs, 16-bit resolution, diagnostics, substitute value function, and voltage/current output support. Ideal for industrial automation and PLC control systems.
The Siemens S7-1500 6ES7532-5HD00-0AB0 is a SIMATIC S7-1500 analog output module, model AQ 4xU/I ST, designed for precise analog signal control in industrial automation systems. It provides 4 analog outputs, supports voltage/current output, offers 16-bit resolution, and includes diagnostics and substitute value functions. Siemens lists this module with 0.3% accuracy and notes that the front connector must be ordered separately.
Features
- Original Siemens SIMATIC S7-1500 analog output module
- Model: AQ 4xU/I ST
- 4 analog output channels
- Supports voltage and current output
- 16-bit resolution for accurate signal control
- Accuracy: 0.3%
- Diagnostics function
- Substitute value function
- Supports safety-oriented shutdown of load groups up to SIL2
- Suitable for S7-1500 and ET 200MP systems
- Includes infeed element, shielding bracket, and shield terminal
- Front connector required separately
Technical Specifications
| Specification | Details |
|---|---|
| Brand | Siemens |
| Series | SIMATIC S7-1500 |
| Article Number | 6ES7532-5HD00-0AB0 |
| Product Type | Analog Output Module |
| Product Designation | AQ 4xU/I ST |
| Number of Outputs | 4 analog outputs |
| Resolution | 16-bit |
| Accuracy | 0.3% |
| Output Type | Voltage / Current |
| Diagnostics | Yes |
| Substitute Value | Yes |
| Firmware Version | V2.2.0 |
| HW Functional Status | From FS04 |
| Dimensions | 35 × 147 × 129 mm |
| Front Connector | Not included; order separately |
| Mounting | SIMATIC S7-1500 / ET 200MP rack system |
Applications
- PLC-based industrial automation
- Analog control of valves, actuators, and drives
- Process automation systems
- Machine control systems
- Factory automation
- Water treatment and utility systems
- Packaging, textile, food, and manufacturing machinery
- Control panels using Siemens S7-1500 PLCs
1. What is Siemens 6ES7532-5HD00-0AB0?
It is a Siemens SIMATIC S7-1500 analog output module, also known as AQ 4xU/I ST, used for analog signal output in PLC automation systems.
2. How many analog outputs does this module have?
The module has 4 analog output channels.
3. What is the resolution of this module?
It provides 16-bit resolution for accurate analog signal output.
4. Does the front connector come with this module?
No. Siemens notes that the front connector must be ordered separately.
5. Is this module suitable for Siemens S7-1500 PLC systems?
Yes, it is designed for the SIMATIC S7-1500 automation system.
6. What industries use this module?
It is commonly used in manufacturing, process control, machine automation, water treatment, packaging, textile, and industrial control panels.
7. Can I request a quotation from Synapse Engineering & Supply?
Yes. You can request a quote with your required quantity, delivery location, and product condition preference.
